the flour mill

At some point someone had hooked up an old exercise bike to a country living grain mill. This is probably the most common form of pedal power to come out of the seventies, at least in the states. (I can't tell you how many aging hippies have told me they had one once on their "farm"). Though this one was not from the seventies, it was built maybe only a few years prior. For all intensive purposes it worked, but not very well.



The first thing i noticed was how rickety it was. It didn't stabilize very well, in part because it was a cheap old bike in rusting disrepair, but it was compounded by the fact that it was twist-tied to a piece of plywood for its base. No welds, no bolts, just pieces of wire once wound tight now loosened with time. Also, the handles weren't rigid, they had some sort of "exercise function" in that they would pivot at the base where it was hooked up to a hydraulic pump. I suppose the idea was that you could work out your arms while you pedaled. But the net affect in its re-purposed form was that you couldn't lean on the handle bars at all, they would just slowly creep forward til they were too far to reach.





The second thing that i noticed was the gearing. The rider would pedal pretty fast, with little resistance, and the mill would turn slowly. This was a pretty obvious waste of energy, and also uncomfortable to use.

The third thing was that the mill was on the ground, meaning you had to bend over to load or unload it. Also, that close to the ground the mill could easily get crap in it that you wouldn't want there. Generally having food processing going on near feet seemed like a bad idea.

So the first thing was to get the actual mill off of the ground. It would need a table. But a table with a slot in it, for the belt, otherwise the bike, or at least the pulley would have to be at table height as well. (In hindsight i can see that having the pulley at the height of the table would have made several things easier, namely building the table, but at the time that didn't occur to me).

I set about designing the table, thinking of the ideal height for accessing the mill, as well as having adequate space for containers and any other necessary equipment. Being average height, i used myself for a reference to determine the approximate measurements.

I came up with a rough design for the table that seemed like it would work well, showed it to Chris (the builder on site) and was shown a source of wood i could use to build it. I wasn't quite ready to build it yet, because i didn't quite know what the mechanical apparatus was actually going to look like. But having the table roughed out helped determine the route of the machine.


The next thing to figure out was how to gear it. I'd learned some very practical points about gear ratios from reading the Human Powered Home, and was very pleased to be able to put them to use right away. Measuring the circumference of the pulley on the mill, the pulley on the flywheel, the cog on the flywheel and the chainring on the bike, i was able to determine the gear ratio of the mill. In other words, i figured out how many times the mill spun for every one full rotation of the pedals. (Don't remember the exact number but it was something really low like 1:1)

Where should the ratio be instead? I wasn't sure, so i just guessed. I figured the mill should spin at least three times for every one full rotation of the pedals. I looked at the measurements i had taken of the existing cogs and pulleys and realized that to step it up to that level would require a chainring much larger than anything commercially available, let alone kicking around in Apro's collection of old bikes. Fortunately, one of the concepts i learned from the Human Powered Home was the idea of compound gear trains. Basically taking several gears of modest size to accomplish what one really big and one really small gear would accomplish. As far as i understand it, the fewer the gears, the fewer the chains, the less friction involved, the greater the efficiency. So the compound gear train wouldn't be the ideal for efficiency, but true to form with appropriate technology it was what was available, easily replicable and reparable. (P.S. from here on out i'm just going to refer to appropriate technology as AT).

So i took a look at some gears that used the same kind of chain, counted their teeth, and came up with an accurate calculation of how many times the mill would spin for every one full rotation of the pedals.


It came out right around where i wanted it, 3.7:1.

I grabbed two bikes to start experimenting with. First i took apart the bottom brackets, cleaned them off and repacked them. I took the flywheel apart and cleaned that too. Put it all back together and onto the bike to make sure it would fit in the dropouts. Got it all hooked up and the chain rode high on the gear of the flywheel. The chain wasn't wide enough. New chain, all better.


I then mocked up a fixture, using the rear end of a bike, for holding a cogsette to complete the gear train. It was too small. So i found a bike with much longer seat stays to give me the distance i needed.


I put the new fixture roughly into place, it looked pretty good. I saw that i would need to put a brace across the chainstays of the bike in order to weld it securely.


My welds still looked pretty bad, but they held. (It was fortunate that i had learned how to weld with a stick welder in Guatemala, because that was exactly what apro had).


I was so excited to see the thing run, that before i even had it all the way welded on i asked Elliott to get it spinning so i could tape it.

I then welded on additional supports using some rebar that was lying around. With that complete i had to figure out exactly where to cut it away from the rest of the bike. As you can see there's no way this thing could run in its current state.


My friend Eleva, one of the students in the SLS, was really intrigued by the whole process and stopped by sometimes to help out. She did the honors of ridding the machine of its unnecessary tubing.


Now that i had the thing apart i could get a clearer sense of how it was going to interact with the table. I positioned it in place, even propping up the mill so that i could get all my measurements set.



With all of the measurements set i could now move forward in building the table for it.

One of apro's major assets is the wood on its land and the proper facilities to fell and process all that wood into homes, furniture, or fuel. So building the table was pretty straightforward.



Once i had the table built i made some adjustments to the machine, namely putting bracing on it to attach it to the table, as well as a strip of angle iron running along the bottom for structural integrity and also to bolt it to the deck.


Once i made sure that it all worked in the shop i took it up to the strawbale porch where it was going to live. I got it all hooked up and asked Jared, the fake Canadian, to give it a test run.

Everything worked great, the resistance was really good, it ground flour much faster, the mill was easy to access, the table served as a good workspace, and the whole thing was very stable. All the old issues had been solved, however, there were a couple of new ones. But i'll come back to that in a minute.

After testing it in place i took it apart again to paint it, for aesthetics, but moreover as a preventative measure against rust. It rains in the northwest all the time, its not just Seattle as my naive east coast upbringing had me believe, no, its everything from northern California all the way up through Canada. Moss and rust. Lots of both.

Building this mill was great for me. Although i'd built several machines in Guatemala and a couple on the east coast, this was most involvement i'd had with anything thus far. It was an awesome opportunity to problem solve, experiment, and construct from near scratch. And the near scratch part was important, at this stage in my learning i don't think i could have made a decent flywheel, let alone one with a pulley attached to it. Having the flywheel and mill already constructed and working was crucial. It was the perfect challenge for me in that moment, i learned a lot in doing it.

With some time and further learning in between myself and the mill there are several things that i can see could be better. Its too big. This is kind of inevitable with pedal powered machines, but this one could definitely be made smaller. The chair would be better suited being attached to the machine, or bolted to the ground as some people end up pushing themselves backwards while trying to pedal. Another way to fix that would have been to put handles on it. Also, the chain, over time, has bent all of the stays towards the drive side of the machine. This could have been avoided with a greater structural engineering emphasis (something i don't know that well). Another way to have fixed that would be to put a derailleur in there somewhere. And that goes for the belt on the mill as well, not a derailleur per se, but a belt tensioner. Belts and chains alike stretch over time and having a way to keep proper tension on them is key to efficiency.

Aprovecho

As things continued to not be all that exciting in philadelphia an interesting opportunity presented itself- a trip west for a wedding. My cousin would be getting married in Boise that summer, and i had a round trip ticket courtesy of my family. Without a lease, a job, a girlfriend, or even a hermit crab to tie me to philly i decided to extend my trip for as long as my money would last. A road trip seemed in order. And while visiting friends i could probably do some presentations and workshops.

I contacted a number of organizations on the west coast, most of them either weren't interested or didn't pan out. One organization, however, was definitely interested and was willing to commit to having me out to do some work. That organization was Aprovecho, a sustainability research and education center in rural Oregon. I had heard of aprovecho years prior through a friend, specifically in reference to the efficient wood burning stove technology that they pioneered- known as rocket stoves.

So road trip i did. From Idaho Falls to Portland, where i picked up my best friend Elliott and we headed down to apro together.

I can't remember what my original length of stay was going to be, maybe a couple of weeks, maybe a month. I remember Elliott stayed for a month, so maybe that was it. As things progressed, however, i ended up staying far longer.

Aprovecho has a wonderful campus outside of Cottage Grove, Oregon (roughly 45 minutes from Eugene). Its on the south side of a mountain, tucked between groves of moss covered fir, in an idyllic setting that's as beautiful as it is peaceful. There are a number of cabins and classroom buildings, constructed with wood from on site, insulated with local straw and finished with plaster made from the clay on site. Aprovecho has a multi-faceted approach to sustainability and they use their campus as a demonstration center for the variety of techniques they employ. Everything from natural building, permaculture, appropriate technology, sustainable forestry, renewable energy and large scale water catchment. Aprovecho runs two Sustainable Living Skills courses per year that cover all of these and more. Elliott and I showed up right at the beginning of their fall '09 SLS.



We were greeted by long term aprovecho student and then employee Jared Webber. He had a cheery disposition and a thick accent that we mistook for Canadian. You're the bike guys from New York? We are, i said. Elliot corrected me, saying he is. Jared then gave us a tour, there weren't very many introductions as Elliot and i were the first to arrive, but we got to see all of the main buildings, and Jared took us down to the shop where i'd be doing my building. It also so happened that the shop was where i was going to be staying, there was a small loft apartment, really a bedroom, above an office built into the shop. Elliott would be staying in the strawbale dormitory simply referred to as 'the strawbale'.

We hung out for a couple of hours, went on a hike, and came back to the strawbale for a pizza party welcoming. The strawbale had an awesome outdoor kitchen, albeit with some logistical and aesthetic problems, but really cool nonetheless. What made it great was that everything was wood fired, there was quite a variety of rocket stoves, there was even a rocket fired oven- made from an actual metal oven. The specificity of the stoves was intriguing, there were stoves built around single pots that fit perfectly inside them, or for a wok, or griddles. They were fascinating and awesome to use.



So standing around the earthen bread oven (not rocket fired) we met a handful of the staff and some of the arriving students. The pizza was awesome and we all chatted for a while. As things died down we did the dishes and made our way to bed.

The shop, a good 400 yards from the main buildings, was where i was headed. Without having the foresight to bring a flashlight i used my ipod to illuminate the way. The room was built ontop of a small office, accessible only by ladder. Up i went. It was cold and smelled weird. The guy who lived there before me had left some art around, an egyptian bust, some weavings and bunch of unhappy looking fish. They disturbed me a little.

Next morning was the official start of the program, there was oatmeal courtesy of Jared, and then introductions outside on the four square court. The crew was the staff, the students and the work-traders (of which Elliott and i were included). Introductions consisted of telling who you are, where you're from, and your favorite joke. I'm terrible with jokes. I never remember any worth telling. I think telling something unique about yourself was an alternative, i'm sure that's what i opted for.

The appropriate technology instructor, Mike Hatfield, was the point person in helping me set up my stay at apro. I was going to be working with him, but when i arrived he was abroad doing stove work so he elected Chris Foraker, the natural builder, to fill in for him for a while. I met up with Chris and we proceeded to do some work together on one of the buildings. After a day or so he showed me my first assignment, to re-design a pedal powered grain mill that they built several years earlier.

urban permaculture

Somewhere in the early summer I headed off to a permaculture workshop in Albany NY (also good excuse to see my friends in the quaker community).

The workshop was being lead by Dave Jacke and Keith Zaltzberg, well known permaculturalists, with assistance from Skott Kellogg, co-founder of the former Rhizome Collective in Austin Texas. The mission of the weekend gathering was to transform the household and yard of my friend Alice, whom I had met at the Rhizome’s Albany RUST training the year prior.

Pretty interesting weekend, lots of brainstorming, demos, work crews, and presentations. All three of the workshop leaders are incredibly knowledgeable and accomplished; they great job of putting together an engaging program based on instruction and action.

I contacted Alice in advance of the workshop and asked if i could bring up a pump i had made since back in the states. She said she thought it would be fine, and so i did. This was a mistake. First off, this thing was ridiculously overbuilt and clunky, and getting it from Philly to Albany was a little cumbersome. Secondly, i can see pretty clearly, in hindsight, that it was fairly opportunistic of me to drag this thing along. I was definitely enthusiastic about what i had learned, and was looking anywhere and everywhere to try to create more opportunities to make more machines and promote Maya Pedal. But, to be entirely frank, it was fairly inappropriate of me to try to interject my agenda into someone else's program.

I'm sure Dave and Keith saw through my ruse, but they were nice about it and carved out 15 mins for me to show the thing off and talk about Maya Pedal.

I was really pleased to get an email after the workshop from a fellow attendee asking to collaborate in the albany area, unfortunately, timing didn't quite line up- i would be on a west coast road trip. A road trip, that unbeknownst to me, was my moving to Oregon.

A rocket-stove heated compost-tea maker (i think). The big barrel in the foreground sits atop the bricks and is heated by small kindling.

Sharon, one of the attendees and a neighbor of Alice, had an awesome terrarium collection. I was really into it.

The Human Powered Home

After leaving Maya Pedal, i knew that i wanted to continue learning about, and building, pedal powered machines. I had a ton of questions about basic physics, gear ratios, efficiency, drive systems, welding, jigs, etc. but with no straightforward or simple way to answer them. I remember thinking out loud to myself "i wish there was a book that was all about this stuff, full of everything that i want to know. " And as fortune would have it, there is such a book- Tamara Dean's "The Human Powered Home."

Dean's book covers all of the basics, and answered almost all of my questions, in an approachable and concise way. She employs the use of graphs and illustrations to make clear any number of concepts from the science of muscle activity to the comparative advantages of different drive systems. The book is full of, not only explorations into human powered projects, but also easy to follow DIY instructions on several machines. Dean does a terrific job of weaving together the history of human power, its current uses, the physics behind it, and a how-to manual all into one.

I highly recommend this book to anyone who is interested in human powered machines, especially those who don't have a science background, and definitely anyone who wants to start building machines. It was the perfect follow up to three months at Maya Pedal.

The Human Powered Home can be purchased online at all the normal places, or on Dean's website (which is worth checking out anyway) at: http://www.thehumanpoweredhome.com/

Lathes For Africa

While I was kicking around Philadelphia an old high school classmate, Josh Raizman, contacted me about a human powered project he was working on. He and a team of engineers were designing lathes to be built in Tanzania, the project was part of his engineering studies at Drexel University.

A professor, not in the engineering department, had a connection with Tanzania. He identified that a human powered lathe could be an important tool to help Tanzanian craftsmen develop low-overhead micro-enterprise. This professor enlisted the help of several highly interested engineering students to help him design a lathe.

At one point there was a website dedicated solely to the project, but I believe it has since been taken down. However, Alex Moseson, one of the graduate students working on the team, has reposted all of the information on his own site here.

Their work was very impressive, aside from the challenge of building a human powered lathe, they also had to design it with limited resources in mind. This is one of the greatest challenges of appropriate technology, making something that is highly functional, easily reparable, and made from locally available materials. I think they did a pretty good job with it. I was also impressed by their flexible power supply- one version they built could be run by bike, could be hooked up to a motor, run by treadle, or you could use the spinning wheels of a jacked up car to operate the lathe. This was a higher order of functionality and versatility then anything I had experienced thus far.

I got a chance to visit Josh, and see one of the lathes that was currently under construction in Drexel’s lab.

It was a great pleasure to see their work in person, ask lots of questions, and delve into some of the issues surrounding appropriate technology and working abroad.

building a blender at Alfred

Next on the tour was Alfred University, specifically the New York State College of Ceramics. I had contacted one of my favorite professors, Diane Cox, who just so happened to be teaching a course on the intersection between art making and sustainability. She loved the idea of having me out and, especially, of having the class build a blender together.

The trip from Albany to Alfred was actually a very familiar one, I’d done it dozens of times. But I’d become so used to being crammed onto crowded buses in Central America for 3 months that riding a greyhound was, by contrast, kind of bizarre. What with its (relatively) luxurious seating, a bathroom on board, and almost no one riding. It was confounding, how could this be profitable?

I came in late, stayed with some good friends in town, and then met up for breakfast with Diane and one of her seniors, a friend of mine, Sam Newman. Diane snagged Sam to help her get everything rolling, and together they did a fantastic job of gathering materials, and of setting up and promoting a small talk that I gave about the trip.

The talk went off well. A nice small crowd came out to hear about Maya Pedal, including some of my former professors. Good to see them, and to get them on the bike.

Diane’s class seemed pretty interested in building the blender and in the machines in general. We only had a few days to build it, but with everyone involved we got it done pretty quick.

(Unfortunately, I misplaced most of the process shots. So we’ll jump forward a bit.) Below is the rough skeleton of the frame sans components. We had several bikes at our disposal, and my memory is that some didn’t work so we had to find more.

This first mock-up, though, was a little too big. So one of the students, Matt Fendya, cut the downtube in half, moved the seat post closer in, welded in a top tube, and then made a clever adjustable seat. This was great for increasing the user accessibility of the machine. The seat, however, leans so far back, that an additional rear brace had to be put on the back.

One of my favorite touches was the appropriation of walmart shopping cart handle bars.

And also the tassles.

And here it is in its final state

And when all was said and done, we had a party at one of the students’ places. Margaritas, were in order. Unfortunately the blender wasn’t so great at chopping ice, so they were a little… chunky. Also, we were somehow missing the top of the blender, so we used some tinfoil, which worked. More or less.

There was some talk of getting the blender into the Moka Joka (the little coffee shop in the art building), I suspect it didn’t make it there though. The question of commercial kitchen quality came up, and uh yeah, this thing was not commercial kitchen quality.

After my departure, Sondra Perry, one of the students put together this video:

blender bike from Sondra R. Perry on Vimeo.

I’m really glad that this trip got put together, that I was able to talk to as many people as I was and able to get the word out about Maya Pedal. I was also really pleased that the learning was going both directions. Not having had any metal working experience prior to Maya Pedal it was great to work with students who had several years of experience. I definitely picked up some tricks I still use to this day.

Another piece that was interesting and instructive was having to relate to a group how to put one of these things together. And furthermore how to break up the tasks into roughly equal parts to keep everyone as engaged as possible. It was definitely a challenge in terms of gauging each persons skill level, speed, and motivation.

At the time I felt strongly that this was something that I would continue doing, or at least attempt to, perhaps even as a vocation. It was from the success of these few visits that I would eventually be convinced to try my luck on the west coast.

*I'd like to give a special thanks to the NYSCC Sculpture Department, Diane Cox, Sam Newman and the students of Art & Ecology for making this trip possible. I'd also like to thank the Alumni Association and Devin Henry for their photo-documentation.
